PCIe 802.11N WIFI+Bluetooth Wlan Wireless Card,IO-mPCETOWB-01_Shenzhen MMUI CO.,Ltd

微信二维码

PCIe 802.11N WIFI+Bluetooth Wlan Wireless Card,IO-mPCETOWB-01

FeaturesCompliantwithBluetooth2.1+EDRandV3.0+HSspecificationsbyonchipsoftwarestackSupportforWLAN+BluetoothcoexistenceforoptimizedperformanceIEEE802.11b/g/ncompliance150MbpsT...

Model：

IO-mPCETOWB-01

Input Interface：

Mini PCIe

Output Interface：

Bluetooth 2.1

Motherboard Slot：

Mini PCIe

Transmission Rate:

Auxiliary Accessories:

Product Size:

Shopify Alibaba Aliexpress

Product Description

Product specifications

Driver Download

Document Download

Q&A

Features
Compliant with Bluetooth 2.1 + EDR and V3.0 + HS specifications by on chip software stack
Support for WLAN + Bluetooth coexistence for optimized performance
IEEE 802.11b/g/n compliance
150 Mbps Tx (Transmit) PHY data rate, and 150 Mbps Rx (Receive) PHY data rate
Compliant with PCIe V1.2 or later
Support for legacy and high throughput Wi-Fi modes
1T1R 802.11n Wi-Fi with antenna diversity
Compressed Block ACK(BA)
Compliant with IEEE 802.11i 64-/128-bit WEP encryption, WAP, WPA-PSK and TKIP, and WPA2(with AES-CCM support)
Support Hardware WAPI/16 BSSID
Compliant with IEEE 802.1e WMM and WMM Power Save
Compliant with international regulations for IEEE 802.11d
Support for both long and short guard intervals
Cisco CCX V1.0,V2.0,V3.0,V4.0 and CCX5.0 compliant
Support for IEEE 802.11s mesh networks
Support for BT Class 1 Operation for better Bluetooth range
Support Full-speed Bluetooth operation with Piconet and Scatternet
Shared Bluetooth and Wi-Fi signal receiving path to eliminate the need for an external
System Requirements
Windows 2000/XP/Server2003/2008/2012/Vista/7/8/10
Package Contents
MiniPCI-E to PCI-E Wireless Adapter x 1
User Manual x 1
Driver CD x 1
Note: Contents may vary depending on country/market

Related Downloads

1. IO-M2F8111H-GLAN frequently asked questions

2. 352.354.358 Q&A on Chip Serial Series Products

3. COMMON PROBLEMS WITH 1061R SERIES PRODUCTS

4. IO-M2F8111H-GLAN frequently asked questions

5. 352.354.358 Q&A on Chip Serial Series Products

6. COMMON PROBLEMS WITH 1061R SERIES PRODUCTS

7. IO-M2F8111H-GLAN frequently asked questions

8. 352.354.358 Q&A on Chip Serial Series Products

9. COMMON PROBLEMS WITH 1061R SERIES PRODUCTS

10. IO-M2F8111H-GLAN frequently asked questions

11. 352.354.358 Q&A on Chip Serial Series Products

12. COMMON PROBLEMS WITH 1061R SERIES PRODUCTS

What are the differences between this card and the usb3.1 10G interface that comes with the computer motherboard itself? Is it more stable than the usb3.0 interface of the computer itself?

It will be more stable than the USB port that comes with the computer itself. The reason is that most of the USB ports of a computer come out of the south bridge of the motherboard. This card directly comes out of the independent USB chip through the PCIE slot directly connected to the CPU, eliminating the south bridge as an intermediate link, which is more efficient and has lower wear and tear

What are the differences between this card and the usb3.1 10G interface that comes with the computer motherboard itself? Is it more stable than the usb3.0 interface of the computer itself?

It will be more stable than the USB port that comes with the computer itself. The reason is that most of the USB ports of a computer come out of the south bridge of the motherboard. This card directly comes out of the independent USB chip through the PCIE slot directly connected to the CPU, eliminating the south bridge as an intermediate link, which is more efficient and has lower wear and tear

What are the differences between this card and the usb3.1 10G interface that comes with the computer motherboard itself? Is it more stable than the usb3.0 interface of the computer itself?

It will be more stable than the USB port that comes with the computer itself. The reason is that most of the USB ports of a computer come out of the south bridge of the motherboard. This card directly comes out of the independent USB chip through the PCIE slot directly connected to the CPU, eliminating the south bridge as an intermediate link, which is more efficient and has lower wear and tear

What are the differences between this card and the usb3.1 10G interface that comes with the computer motherboard itself? Is it more stable than the usb3.0 interface of the computer itself?

It will be more stable than the USB port that comes with the computer itself. The reason is that most of the USB ports of a computer come out of the south bridge of the motherboard. This card directly comes out of the independent USB chip through the PCIE slot directly connected to the CPU, eliminating the south bridge as an intermediate link, which is more efficient and has lower wear and tear

What are the differences between this card and the usb3.1 10G interface that comes with the computer motherboard itself? Is it more stable than the usb3.0 interface of the computer itself?

It will be more stable than the USB port that comes with the computer itself. The reason is that most of the USB ports of a computer come out of the south bridge of the motherboard. This card directly comes out of the independent USB chip through the PCIE slot directly connected to the CPU, eliminating the south bridge as an intermediate link, which is more efficient and has lower wear and tear
