USB3.0 TO HUB and Card Reader,IO-HCR7481-2UR

Productdescription：Features *SupportUSB3.0SpecificationRevision1.0.*SupportUSBSpecificationRevision2.0*UpstreamPortsupportSuperSpeed,High-SpeedandFull-SpeedConnections*ForDowns...
Model：
IO-HCR7481-2UR
Input Interface：
USB
Output Interface：
USB
Motherboard Slot：
Transmission Rate:
Auxiliary Accessories:
USB3.0 Cable
Product Size:
Shopify Alibaba Aliexpress
深圳乐扩多
深圳乐扩多
深圳乐扩多
深圳乐扩多
深圳乐扩多
深圳乐扩多
Product Description
Product specifications
Driver Download
Document Download
Q&A
Product description：

Features
*Support USB 3.0 Specification Revision 1.0.
*Support USB Specification Revision 2.0
*Upstream Port support SuperSpeed, High-Speed and Full-Speed Connections
*For Downstream Ports Support SuperSpeed, High-Speed, Full-Speed and Low-Speed Connections
*Implement USB3.0 power management function
*USB2.0 Link Power Management support
*USB Attached SCSI Protocol Revision 1.0 Compliance
*Multiple Transaction Translator Support
*Gang mode Support for Port 2, 3, 4
*Remarkable with Removable or permanently attached
*Self-power and bus-power support
*Support USB Mass Storage Class, Bulk-Only Transport Specification.
*Support USB 3.0 U0/U1/U2/U3 (P0/P1/P2/P3) and USB 2.0 L0/L1/L2 power saving modes.
*Support Secure Digital v1.0/v1.1/v2.0 SDHC/SDXC (Capacity up to 2TB).
*Support Secure Digital v3.0 UHS-I (Ultra High Speed)SDR12/SDR25/SDR50/DDR50/SDR104.
*Support MultiMediaCard (MMC) specification v4.1/v4.2 x1/x4 bit data bus and DDR x4 bit data transfer mode.
*Support user data locking, providing a privacy protection solution.
*Support SD Lock/Unlock Function.
*External Serial Flash memory interface.
*Compliant with USB bus-powered and self-powered power consumption requirements.
*Consumed less than 2.5mA  in USB 3.0 and USB 2.0 suspend mode
Package Contents
1 x USB3.0 HUB and Reader Controller
1 x User Manual
1 x USB3.0 Cable
Note: Contents may vary depending on country and market.
System Requirements:
Windows Server 2003, 2008,2012
Windows 2000/ME, XP, Vista, 7, 8
Linux and Mac OS 9.x/10.x. or later version
Driver Installation
Windows will automatically detect and install the drivers for the USB3.0 to Device.
Note: This device is plug-and-play, so no driver is needed.


Related Downloads
1. IO-M2F8111H-GLAN frequently asked questions
Download
2. 352.354.358 Q&A on Chip Serial Series Products
Download
3. COMMON PROBLEMS WITH 1061R SERIES PRODUCTS
Download
4. IO-M2F8111H-GLAN frequently asked questions
Download
5. 352.354.358 Q&A on Chip Serial Series Products
Download
6. COMMON PROBLEMS WITH 1061R SERIES PRODUCTS
Download
7. IO-M2F8111H-GLAN frequently asked questions
Download
8. 352.354.358 Q&A on Chip Serial Series Products
Download
9. COMMON PROBLEMS WITH 1061R SERIES PRODUCTS
Download
10. IO-M2F8111H-GLAN frequently asked questions
Download
11. 352.354.358 Q&A on Chip Serial Series Products
Download
12. COMMON PROBLEMS WITH 1061R SERIES PRODUCTS
Download
乐阔多
What are the differences between this card and the usb3.1 10G interface that comes with the computer motherboard itself? Is it more stable than the usb3.0 interface of the computer itself?
It will be more stable than the USB port that comes with the computer itself. The reason is that most of the USB ports of a computer come out of the south bridge of the motherboard. This card directly comes out of the independent USB chip through the PCIE slot directly connected to the CPU, eliminating the south bridge as an intermediate link, which is more efficient and has lower wear and tear
乐阔多
What are the differences between this card and the usb3.1 10G interface that comes with the computer motherboard itself? Is it more stable than the usb3.0 interface of the computer itself?
It will be more stable than the USB port that comes with the computer itself. The reason is that most of the USB ports of a computer come out of the south bridge of the motherboard. This card directly comes out of the independent USB chip through the PCIE slot directly connected to the CPU, eliminating the south bridge as an intermediate link, which is more efficient and has lower wear and tear
乐阔多
What are the differences between this card and the usb3.1 10G interface that comes with the computer motherboard itself? Is it more stable than the usb3.0 interface of the computer itself?
It will be more stable than the USB port that comes with the computer itself. The reason is that most of the USB ports of a computer come out of the south bridge of the motherboard. This card directly comes out of the independent USB chip through the PCIE slot directly connected to the CPU, eliminating the south bridge as an intermediate link, which is more efficient and has lower wear and tear
乐阔多
What are the differences between this card and the usb3.1 10G interface that comes with the computer motherboard itself? Is it more stable than the usb3.0 interface of the computer itself?
It will be more stable than the USB port that comes with the computer itself. The reason is that most of the USB ports of a computer come out of the south bridge of the motherboard. This card directly comes out of the independent USB chip through the PCIE slot directly connected to the CPU, eliminating the south bridge as an intermediate link, which is more efficient and has lower wear and tear
乐阔多
What are the differences between this card and the usb3.1 10G interface that comes with the computer motherboard itself? Is it more stable than the usb3.0 interface of the computer itself?
It will be more stable than the USB port that comes with the computer itself. The reason is that most of the USB ports of a computer come out of the south bridge of the motherboard. This card directly comes out of the independent USB chip through the PCIE slot directly connected to the CPU, eliminating the south bridge as an intermediate link, which is more efficient and has lower wear and tear
